T64 Self-Drilling Anchor Bolt
T64 offers significantly enhanced tensile and compressive capacity, with high rigidity and strong load-bearing performance, making it suitable for deep-hole anchoring and deep reinforcement of surrounding rock.
Products Categories
Get A Free Quote
Product Specifications
Hollow Anchor Bar
| Size | Outer Dia. | Ultimate Load | Yield Load | Weight | |||||
| mm | in | kN | kips | kN | kips | kg/m | lbs/ft | ||
  |
SST64 | 64 | 2.52 | 1160 | 261 | 930 | 209 | 13.00 | 8.74 |
| Note： 1. Customized products are available based on your specific requirements； 2. 1mm=0.03937in 1kN=0.225kips 1MPa=0.1450377ksi 1kg/m=0.672 lbs/ft |
|||||||||
Coupler
| Size | Outer Dia. | Length | Weight | Note | |||||
| mm | in | mm | in | kg | lbs | ||||
| SST64 | 80 | 3.15 | 180 | 7 | 2.52 | 5.54 | With sealing ring | ||
Hex Nut
| Size | Key Size | Length | Weight | Note | |||||
| mm | in | mm | in | kg | lbs | ||||
 |
SST64 | 85 | 3.35 | 70 | 2.76 | 1.61 | 3.54 | Heat treatment | |
Domed Nut
| Size | Key Size | Length | Weight | Note | |||||
| mm | in | mm | in | kg | lbs | ||||
 |
SST64 | 85 | 3.35 | 80 | 3.15 | 2.13 | 4.69 | Heat treatment | |
Flat Plate
| Size | Dimensions | Thickness | Hole Dia. | Weight | |||||
| mm | in | mm | in | mm | in | kg | lbs | ||
 |
SST64 | 250×250 | 6.89×6.89 | 50 | 1.97 | 70 | 2.76 | 23.02 | 50.64 |
Drill Bit
| Size | Outer Dia. | Application (Advice) | ||||||
| mm | in | |||||||
 |
EX | Sand, fills, gravel | ||||||
| SST64/130 | 130 | 5.12 | ||||||
 |
EXX | Softer sedimentary rocks such as marls, mudstones, siltstone | ||||||
| SST64/130 | 130 | 5.12 | ||||||
 |
EXX(Venturi) | |||||||
| SST64/125 | 125 | 4.92 | ||||||
 |
Clay Bit | Clay, soft soil, marls, loose sand or gravel | ||||||
| SST64/130 | 130 | 5.12 | ||||||
 |
ES-F | Gravel, soft rock | ||||||
| SST64/130 | 130 | 5.12 | ||||||
 |
ESS-F | Weathered rock, stone walls, rubble | ||||||
| SST64/90 | 90 | 3.54 | ||||||
| SST64/130 | 130 | 5.12 | ||||||
