T111 Self-Drilling Anchor Bolt
T111 features a large bar diameter and robust overall structure, making it suitable for reinforcement projects requiring extra-long anchoring, deep anchoring, and high structural stability beyond the capabilities of conventional anchor bolts.
Products Categories
Get A Free Quote
Product Specifications
Hollow Anchor Bar
| Size | Outer Dia. | Inner Dia. | Ultimate Load | Yield Load | Weight | ||||||
| mm | in | mm | in | kN | kips | kN | kips | kg/m | lbs/ft | ||
 |
SET111L | 111 | 4.37 | 78 | 3.07 | 2640 | 594 | 2000 | 450 | 28.50 | 19.15 |
| SET111N | 111 | 4.37 | 64 | 2.52 | 3650 | 821 | 2750 | 619 | 39.50 | 26.54 | |
| Note： 1. Customized products are available based on your specific requirements； 2. 1mm=0.03937in 1kN=0.225kips 1MPa=0.1450377ksi 1kg/m=0.672 lbs/ft |
|||||||||||
Coupler
| Size | Outer Dia. | Length | Weight | Note | |||||
| mm | in | mm | in | kg | lbs | ||||
 |
SST111 | 140 | 5.51 | 250 | 9.84 | 12.60 | 27.72 | With sealing ring | |
Hex Nut
| Size | Key Size | Length | Weight | Note | |||||
| mm | in | mm | in | kg | lbs | Heat treatment | |||
 |
SST111 | 150 | 5.91 | 120 | 4.72 | 10.20 | 22.44 | ||
Flat Plate
| Size | Dimensions | Thickness | Hole Dia. | Weight | |||||
| mm | in | mm | in | mm | in | kg | lbs | ||
 |
SST111/82 | 300×300 | 11.81×11.81 | 80 | 3.15 | 130 | 5.12 | 47.80 | 105.16 |
| SST111/75 | 350×350 | 13.78×13.78 | 90 | 3.54 | 130 | 5.12 | 76.80 | 168.96 | |
Centralizer
| Size | Outer Dia. | Length | Weight | ||||
| mm | in | mm | in | kg | lbs | ||
 |
SET111 | 170 | 6.69 | 50 | 1.97 | 1.80 | 3.96 |
Drill Bit
| Size | Outer Dia. | Application (Advice) | ||||||
| mm | in | |||||||
 |
EX | Sand, fills, gravel | ||||||
| SST111/220 | 220 | 8.66 | ||||||
 |
EXX | Softer sedimentary rocks such as marls, mudstones, siltstone | ||||||
| SST111/220 | 220 | 8.66 | ||||||
 |
Clay Bit | Clay, soft soil, marls, loose sand or gravel | ||||||
| SST111/220 | 220 | 8.66 | ||||||
 |
ESS-F | Weathered rock, stone walls, rubble | ||||||
| SST111/170 | 170 | 6.69 | ||||||
| SST111/200 | 200 | 7.87 | ||||||
